Parrot ANAFI Assembly/Disassembly Manual

ANAFI assembly and disassembly processes 9
- Remove the screws closest to the center of the GPS card.
- Remove the screws holding the hinges: a screw can be found at each extremity of the GPS
card. Do not forget to remove screws from the bottom of the drone as well.
- Retract the arms towards the body of the drone before removing the black plastic holder of
each hinge.
- Push the lower side of each hinge to remove them.
- Caution: a washer will fall off from each hinge when removed, make sure that you do not
lose them.

Parrot ANAFI Specifications

General

Type	Quadcopter
Product color	Black
Housing material	Carbon
Maximum speed	55 m/s
Frequency band	2.4, 5 GHz
Number of rotors	4 rotors
Maximum weight capacity	- kg
Maximum operating distance	4000 m
Built-in processor	-
Memory card slot(s)	Yes
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	64 GB
Megapixel	21 MP
Sensor type	CMOS
Video resolutions	3840 x 2160 pixels
Maximum frame rate	60 fps
Optical sensor size	1/2.4 \
Camera shutter speed	1 - 1/10000 s
Image formats supported	DNG, JPEG
Video formats supported	MP4
Field of view (FOV) angle	84 °
Bitrate at maximum video resolution	100 Mbit/s
Charging time	105 min
Operating time	25 min
Battery voltage	7.6 V
Battery capacity	2700 mAh
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Weight	320 g
