Installation
We would advise our customers to have the Parrot
MKi9000 fitted by a professional.
• The cables supplied with the kit feature ISO connectors and
two pairs of line-out jacks. The line-out jacks can be used if
your audio system features this option (use of an amplifier).
Several set-ups are therefore possible depending on the
type of car stereo and your vehicle.
• Prior to fixing the hands-free kit’s different components
inside the car, connect the installation cables, con-
trol keypad and double microphone to the electronic
control unit.
• The mute function is used to cut the sound of your car ste-
reo to enable a phone call. The choice of the mute-in jack
depends on your car stereo’s configuration.
Car stereo with an ISO connector
1. Connect the male connectors of the hands-free kit to
the car stereo.
2. Join the vehicle’s audio and power supply cables to the
female connectors of the Parrot MKi9000.
3. On the installation cable, connect the free yellow wire to
one of the audio system’s corresponding mute-in jacks if
available (mute in 1, mute in 2 or mute in 3).
If your car stereo is not equipped with ISO connec-
tors, you will need to purchase an ISO adapter cable
to simplify the wiring procedure. Refer to the range of
ISO adapters on our website: www.parrot.com.
Car stereo with line-in jacks
• Use this type of connection by wiring a line-out jack
(brown & white wire or red & black wire) to your car
stereo’s line-in jack.
• Using the two pairs of line-out jacks will enable you to take
advantage of the streaming audio function in stereo over
your vehicle’s speakers.
• On the installation cable, connect the free yellow wire to
one of the audio system’s corresponding mute-in jacks if
available (mute in 1, mute in 2 or mute in 3).
Installing the kit’s power cable
Refer to your car stereo’s wiring diagram.
• The red wire of the kit’s cable must correspond to the con-
stant +12V supply, the orange wire to the ignition +12V and
the black wire to ground.
• Check that the orange wire is not connected to the constant
12
