22 – English
TECHNICAL DATA
Engine
Cylinder volume, cm
3/
cu.in 93,6/5,7
Cylinder bore, mm/inch ∅ 56/2,2"
Stroke, mm/inch 38/1,5"
Idle speed, rpm 2 500 rpm
Recommended max. speed, unloaded, rpm 9 800 ± 300
Power, kW 4,5
Ignition system
Manufacturer FHP
Spark plug Champion RCJ-7Y
Electrode gap, mm/inch 0,5 (.020")
Fuel and lubrication system
Manufacturer Tillotson
Carburettor type HS 282A
Fuel capacity, litre/US Pint 1,0/2,10
Weight
Without fuel and cutting blade, kg/Lbs
12" (∅ 300 mm) 9,9/21,8
14" (∅ 350 mm) 10,3/22,7
16" (∅ 400 mm) 11,2/24,7
Sound levels
Equivalent
(see note 1)
sound pressure level at
the user’s ear, measured according to EN 1454
and ISO/DIS 11201, dB(A). 102,6
Equivalent
(see note 1)
sound power level, measured
according to EN 1454 and ISO 3744, dB(A). 111,7
Vibration levels
Handle vibrations measured according to EN 1454.
Front handle, idling, m/s
2
8
Front handle, full speed, m/s
2
6
Rear handle, idling, m/s
2
9
Rear handle, full speed, m/s
2
8
Note 1.
Equivalent sound level is calculated as the time weighted energy total
for sound levels under different operating conditions during the following time
divisions 1/2 idling, 1/2 full speed.
Cutting equipment
Cutting blade Gear ratio Max. peripherical speed
12" 0,52 80 m/s
14" 0,52 100 m/s
16" 0,42 100 m/s
EU declaration of conformity (Only applies to Europe)
(Directive 89/392/EEC, Annex II, A)
We, Partner Industrial Products, S-433 81 Partille, Sweden, tel. +46-31-949000, declare under sole responsibility that the
power cutter Partner K950 Active from the serial numbers of 1998 and onwards (the year is clearly stated in plain text on the
type plate with subsequent serial number), is in conformity with the following standards or other normative documents following
the provisions in the COUNCIL’S DIRECTIVES:
- of June 14 1989 “relating to machinery” 89/392/EEC and applicable supplements.
- of May 3 1989 “relating to electromagnetic compatibility” 89/336/EEC, and applicable supplements.
The following standards have been applied: EN292-2, EN1454.
Partille October 19, 1998
Bo Andréasson, Development manager.
