TITLE : RP-300/310
Page -72 -
·The commands which set the printing area width for bit image printing
and its minimum widths are as follows:
·Bit image (ESC *) :
Single density mode = 2 dots
Double density mode = 1 dot
·Downloaded bit image (GS /):
Double width mode or Quadruple mode = 2 dots
Normal mode or Double-height mode = 1 dot
·NV bit image (FS p) :
Double width mode or Quadruple mode = 2 dots
Normal mode or Double-height mode = 1 dot
·Raster bit image (GS v 0) :
Double width mode or Quadruple mode = 2 dots
Normal mode or Double-height mode = 1 dot
[Default]
nL = 0, nH = 2
[Reference] GS L, GS P
GS ＼ nL nH
[Name] Set relative vertical print position in page mode
[Format] ASCII GS ＼
nL nH
Hex 1D 5C
nL nH
Decimal 29 92
nL nH
[Range] 0 ≤
nL ≤ 255
0 ≤
nH ≤ 255
[Description] Sets the relative vertical print starting position from the current position in
page mode.
·This command sets the distance from the current position to [(
nL + nH x
256) vertical or horizontal motion unit] inches.
[Details] ·This command is ignored unless page mode is selected.
·When pitch N is specified to the movement downward:
nL + nH x 256 = N
