PASECO IH75000 - 3. UNPACKING AND ASSEMBLY

5
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
Handle
Wheels
Wheels Caps
Cord Wrap
Cord Wrap
Screws
Hardware Kit Part No :
HW-KFA1001
Hardware Kit Part No : HW-KFA1008
Screws(A) Screws(B)
Washers
Cotter Pins
Front Handle
Louvre
3. UNPACKING AND ASSEMBLY
1. REMOVE THE HEATER AND ALL PACKING MATERIALS FROM THE BOX.
NOTE : Save the shipping carton and packing materials for future storage.
IH75000 IH125000 IH170000
seYseYoNleehW
Wheel Axle No Yes Yes
Wheel Cap No Yes Yes
Front Handle No Yes Yes
seYseYseYeldnaH
Cord Wrap Yes Yes Yes
seYseYoN
Louvre
Hardware Kit : HW-KFA1001 Yes No No
Hardware Kit : HW-KFA1008 No Yes Yes
Wheel Axle
Figure 4. IH75000 MODEL
Figure 5. IH125000/IH170000 MODELS
