PARTS LEGEND
PowerMaster Pro
™
F-350P, 515000
▲
1
501043 1 T.H.S.C.S. 1/4 -20 x 1/2”
2
501016 1 Air Deflector
3
501300 4 S.H.C.S. 1/4-20 x 1-1/4”
4
5
501017 1 Cap
6
500461 1 O-Ring
7
092042 2 O-Ring
8
500407 1 Spring, Main Valve
9
501001 1 Gasket, Cap
10
406041 1 Retaining Ring
11
500455 1 Upper Valve Piston
12
401946 1 Seal, Main Valve
*13
091208 1 O-Ring
14
401950 1 O-Ring
16
500456 1 Lower Valve Piston
15
500454 1 Post
17
095432 1 O-Ring, Post
18
500453 1 Bumper, Post
19
402906 1 B.H.S.C.S.10-32 x 5/8"
092971 1 O-Ring, Piston
■
21
501218 1 Driver Blade
22
402011 1 Seal Sleeve
23
501283 1 Sleeve
24
092235 1 O-Ring, Sleeve
25
501002 1 O-Ring, Midcheck
27
500866 1 Bumper
28
515017 1 Housing
30
500779 1 Flange, Sleeve
26
31
32
33
34
35
36
37
38
41
42
515003 1 End Plug
43
501299 2 S.H.C.S. 1/4-20 X 1”
44
45
502930 1 Spring, Rafter Hook
46
515005 1 Rafter Hook
47
515018 1 Bushing, Rafter Hook
▲
48
444786 1 S.H.C.S. ,1/4-20 x 5/8”
49
515002 1 Nose, 30º
50
095417 4
Lockwasher 5/16
51
009016 4 S.H.C.S. 5/16-18 x 1”
52
502014
2 Magazine Isolator
53
515016 1 Compression Spring
54
502050 1 Detent Body
55
404361 1 Roll Pin 1/8” x 1/2”
56
515004 1 Upper W.C.E.
57
515010 1 Detent Spring
58
502049 1 Detent Ball
59
502299 1 Thumbwheel
60
515006 1 Lower W.C.E.
61
515008 1 1/4-20 x 3/8”
62
515009 1 Warning Label
63
442681 2
64
502038 1
65
502029 1
Magazine Cap
66
502031 2
S.H.C.S. 8-32 x 1"
67
68
515020 1
S.H.C.S. 8-32 x 1/2”
Label, Magazine
69
502017 2 B.H.C.S. 1/4”-20 X 3/4”
**
70
502019 1 Follower Claw
72
29
502021 1 Lockout Bar
20
500729 1 Blade Seal
75
501337
1
Piston
502025 1
* Denotes Normal Wear Items
** Make sure Warning Label (Part No. 515009)
is properly affixed. Replace if necessary.
▲ Apply Loctite 242 (Blue) Part No. 093500
■ Apply Loctite (Green)
➔ Denotes New Change
Note: For optimum performance Paslode
recommends the use of a 3/8” Male fitting.
WARNING
A
ll parts must be periodically inspected
and replaced if worn or broken. Failure to
do this can affect the toolʼs operation and
present a safety hazard.
AIR CONSUMPTION - SCF/FASTENER
AIR PRESSURE - PSIG
.082
SCF
AIR CONSUMPTION CHART
*
*
*
*
*
500249 1 O-Ring, Sleeve
•
515013
1 Label, Housing Logo-Right
*
*
*
*
*
071297
3
Roll Pin
401598
1
Valve Body
097746
1
Valve Pin
092174
1
O-Ring, Valve Body
097748
1
Spring, Valve Pin
Locknut, 1/4-20
404325 2 Locknut #8-32
71
403796 1 Roll Pin
73
511118 1 Follower Body
74
502020 1 Follower Spring
Drum Pin Assembly
77
501008 1
501009 1
76
502026 1
Lever, Bottom Trip
39
402669
1
Pin Trigger
40
*
*
515012
1 Label, Housing Logo-Left
Spirol Pin
501010 1
Bump trigger
Negator Spring
10
*
*
*
*
501039
1
Sequential Trigger
402668
1
Retaining Ring
