PAT DS350 G User Manual

DS 350 G Boom Control Troubleshooting- TMS/TTS870 / RT865 BXL
031-300-190-039 Rev. B 4/30/99
10
7. Boom Control Flow
Operator moves
controller to extend or
retract position.
Directional pressure
switch transmits signal
to B.C.S.
B.C.S. checks input for
Automode.
Operation in manual
mode.
off
B.C.S. checks input for
A mode or B mode.
on
B.C.S. checks the
retract and % reset
switch and boom
length. Refer to section
6 for sequencing
information.
Console displays
length and % of each
section.
correct
B.C.S. defaults into a
rigging mode, console
displays error code or
dashboard warning
light indicates "out of
sequence". Refer to
section 16 for BCS
error codes
incorrect
continue on next
page
Drawing 2a.
