DS 350 G Boom Control Troubleshooting- TMS/TTS870 / RT865 BXL
031-300-190-039 Rev. B 4/30/99
18
10.1 DS 350 G LMI central unit (751) - TMS/TTS 870 & RT 865 BXL
3rd wrap warning
relay board
Digital input
extension board
Analog output
extension board
Decoder board Termial board
Diode extension
board
Real time clock (Timer board)
with e-prom sockets
Diode extension
board
Key to open central unit
enclosure
Drawing 9.
PAT Equipment Corporation reserves proprietary rights to this drawing and to the data shown there on. The drawing and data are
confidential and are not to be used or reproduced without the written consent of PAT Equipment Corporation. This drawing is subject to
technical modification without prior notice.
