DS 350 G Boom Control
Troubleshooting- TMS/TTS870 / RT865 BXL
031-300-190-039 Rev. B 4/30/
99
54
15. Continuation
Continuation
Is the
voltage correct?
[O turns = - 500mV
10 turns= - 4.5V]
Possible main board defect. Contact
authorized service dealer for further
assistance.
Yes
No
Defective length potentiometer
assembly. Replace and adjust length
potentiometer. Refer to drawing on
page 18.
56
58
Table of Contents
Default Chapter
3
Table of Contents
3
1 General Information
4
2 Reference Material
4
3 Warnings
4
4 Service and Maintenance
5
5 Boom Control Interface
6
6 Boom Sequence
12
7 Boom Control Flow
13
8 Ramping
15
DS 350 G - Boom Components and Setup
16
Length Transducer Adjustment
18
DS 350 G Superstructure Components - TMS/TTS 870
19
DS 350 G Superstructure Components - RT 865 BXL
20
DS350 G LMI Central Unit (751) - TMS/ TTS 870 & RT 865 BXL
21
LMI Terminal Board - TMS/ TTS 870 & RT 865 BXL
22
Wiring Schematic - TMS/ TTS 870
23
Wiring Schematic - RT 865 BXL
28
12 Boom Length Percentage Error
32
13 Main Boom Length Error
40
14 Inner MID Length Error
46
15 Center MID Length Error
52
16 No Extend or Retract Function in Automode
58
17 Out of Sequence Warning
60
Additional Error Codes - Operational
65
Additional Error Codes -System
66
