DS 350 G Boom Control
Troubleshooting- TMS/TTS870 / RT865 BXL
031-300-190-039 Rev. B 4/30/
99
61
17. Continuation
Is the
voltage
correct?
Yes
No
Check the signal at terminal 10 (24V) and
9 (GND) in CM junction box. Refer to section 9.1 and 11.
Retract all boom section in
manual mode and let the
system reset boom percentage.
Recheck.
Continuation
Defective OM retract
switch. Replace
proximity switch. Refer
to section 9. and 11.
End
63
65
