Patlite LR4 - Page 16

16
1
2
3
4
5
6
Direct Mount with M12 Connector
( )
■
WC
No.
Name
1
2
Head Cover
3
LED Unit
4
Body
5
Direct Mount Bracket
6
Waterproof Packing(t=1)
M30 Nut
Material
PC
Silicone Rubber
PC
PC
Globe
: PC
PC
02
（
Unit
:
mm
）
LR6 - □02WCNW
40
∅
60
19
LR6 - 02 : 126
LR6 - 302 : 246
25
10
∅
52
M30
×
1.5
1/2’’ NPT Internal Threads
・Maximum Board Thickness : 10
