Patlite LR4 - Compatible Models

61
Specifications
SZP-002U
Accessories:
Pole Waterproof Ring
Binding Head Tapping Screw (2 pcs.)
Circular Bracket
Material
Mounting Location
Model
SZP-002U
Remarks
Mass (Tolerance ±10%)
Indoor Only
ADC12
0.11kg
Protection Rating
IP20 (with product attached)
Compatible Pole
POLE22-0100AN,POLE22-0300AN
POLE22-0500AN,POLE22-0800AN
POLE22-1000AN
POLE22-0100ANK,POLE22-0300ANK
POLE22-0800ANK
〈Note〉
● It's possible to run a cable out from the side.
Outer Dimensions
Mounting Dimensional Drawing
※No Accessories
There are no contents of controlled
substances exceeding the threshold
for the RoHS Directive.
（Unit
:
mm
）
-
PJ
LR4
-
PJLR5
,
,
QJ
-
PJ
LR6
QJ
Compatible Models
KT
-
LR7 KT
※
1
※
1
002
Circular Bracket
U
SZP -
Model
U
Body Color
Silver
Model Number Configuration
(※1)Requiredpoleisnotincludedwith.
KT
(Unit : mm)
Mounting Dimensional Drawing ■
SZP-002U
Mounting Hole
(φ5×4 places)
Mounting Hole
(φ5×4 places)
φ54~φ56
90°
Wire Distribution
Hole (φ12)
φ73
∅
94
Pole
∅21.7
0.6 N m
Recommended Torque
M4
Screw/Nut
(∅29)
43
(21)
