Patlite LR4 - Installation Figure

70
■
12.2 Nm
Recommended screw Torque
30 N m
Recommended Nut Torque
Feed the wiring
through the hole
and set the pole
in place to install.
3
3
3
2
1
Mounting
Surface
（
Unit: mm
）
L-bracket
Mounting
Hole
(φ9)
20
1
Mounting
Surface
L-bracket
Mounting
Hole
(φ11)
35
For M8 screw and nut size
For M10 screw and nut size
Installation Figure
SZL-001
3
75
55
（20）
80
32
(5)
∅
9
2-
∅
11
∅
22.5
∅
5
(R20)
(R20)
Opposite
Side
27
SZL-001
L-bracket
Installation Figure
Outer Dimensions
（Unit
:
mm
）
Mounting Location
Model
SZL-001
Remarks
Mass (Tolerance ±10%)
Indoor Only
0.09kg
Material SPHC-P
Specifications
There are no contents of controlled
substances exceeding the threshold
for the RoHS Directive.
-
LJ
LR4
-
LJLR5
-
KTLR7
,
,
LJ
LR6
-
Compatible Models
KT
※
1
Compatible Pole
POLE22-0100AT
POLE22-0300AT,POLE22-0500AT
POLE22-0800AT,POLE22-1000AT
※
1
(※1)Requiredpoleisnotincludedwith.
KT
