Patlite LR4 - Page 71

71
(Unit: mm)
Mounting Dimensional Drawing■
SZQ-001W
Mounting Hole
(
φ
6×4 places
）
φ54~φ56
90°
18.5
Wire Distribution Hole
(φ15)
φ73
Mounting Hole
(
φ
6×4 places
）
1.4 N m
Recommended Torque
M5
Screw/Nut
86.1
36.9
79
70
Pole
∅21.7
70
（
49
）
SZQ-001W
Folding Bracket
Accessories:
Pole Waterproof Ring
Binding Head Tapping Screw ( 2 pcs.)
POLE22-0100AN,POLE22-0300AN
POLE22-0100ANK,POLE22-0300ANK
Compatible Pole
Specifications
Protection Rating
Mounting Location
Model
Material
SZQ-001W
Remarks
Mass (Tolerance ±10%)
Indoor Only
IP65 (with product attached）
PC
0.09kg
Outer Dimensions
Mounting Dimensional Drawing
※No Accessories
There are no contents of controlled
substances exceeding the threshold
for the RoHS Directive.
（Unit
:
mm
）
-
PJ
LR4
-
PJLR5
,
,
QJ
-
PJ
LR6
QJ
Compatible Models
KT
-
LR7 KT
※
1
※
1
001
Circular Bracket
W
SZQ -
Model
W
Body Color
Off-white
Model Number Configuration
(※1)Requiredpoleisnotincludedwith.
KT
