Patlite LR4 - Page 18

18
1
2
3
4
LR5 : ∅
50
LR7 : ∅
70
80
19
6 pcs. 6 pcs.
3 pcs. 3 pcs.
Mounting Bracket with knock-outs and Terminal (Body Unit)
（
Unit
:
mm
）
■
KT
Accessory
LR5 -
KT LR7
-
KT
Hexagon Nut with Flange （M3） Hexagon Nut with Flange （M4）
1 pc.
Pole Waterproof Ring
Hexagon Bolt （M4 x 20）Hexagon Bolt （M3 x 20）
No.
Name
1
2
Head Cover
3
4
Body
Mounting Bracket with knock-outs
Waterproof Packing Silicone Rubber
Material
PC
PC
PC
1 pc.
Pole Waterproof Ring
