23
Caution
Warning
● When using multiple LED units of the same color,
make the contact capacity equal to the number of same color
LED units multiplied
by the contact capacity for 1 tier.
(This is because LED units of the same color light up for one signal line.)
● To protect the power supply and other internal circuitry, be sure to install an external
fuse
.
● If wiring is extended beyond its factory length,
a relevance in the length of the wire and wire gauge
will cause a
voltage drop.
● Be sure the power is disconnected before wiring and changing fuses. Possible cause of short-circuiting may occur.
● Ensure the proper working voltage is used and that direct current or alternating current is properly applied.
Possible cause of damage may occur.
● Do not apply voltage to the Flashing Common line( , ).
Apply voltage to the source line ( ) only. Failure to comply will result in product damage.
● Do not control the flashing display by switching the power source ON and OFF for . Product failure will occur.
● It is not necessary to connect to an external lead for tiers not used. When an extra lead is not connected, it should be
individually insulated with electrical tape or something similar. Failure to comply will result in damage due to short
circuiting.
● Do not pull the lead wire or push it inside the body. Product failure may occur.
Notice
LED Red
/ ①
Red
Function Name
Lead Wire Color
（Cable type）
Pin No.
（ Direct Mount with Terminal Block ,
Mounting Bracket with knock-outs
Terminal
Block）
WT
KT
Refer to pg. 32 “
Terminal Block Array
”
〈Note〉The lead wire color does not indicate
the LED luminescence color.
LED Red
⑥
Function Name
Pin No.
（
Direct Mount with M12 Connector
）
WC
Refer to pg. 33 “
M12 Connector Pin Layout
”
Wiring Example Index
WJ LJ PJ QJ WT KT
Wiring Example Index
WC
02
01
M2
M2
Wiring
5
