General Specifications（ 02 WC ）
Max.
LED Unit：40mA
24V DC
Operating Voltage Range
Rated Voltage ±10%
Typ.
Max.
Typ.
Signal Wire Current
Rated Voltage
（Per Unit）
Rated Power Consumption
（Per Unit）
LED Unit ： 1W
LED Unit ： 1.3W
Upright
Upright
IP65(IEC 60529) / NEMA TYPE 4X,13
Mass(Tolerance ±10%) LR6-302WCNW 0.35kg 0.17kgLR6-02WCNW
Mounting Direction
Environmental Condition
Insulation Resistance
Outer Dimensions
Refer to Section 3 “
Part Names and Outer Appearance”
More than 1MΩ at 500VDC between live part and non-current carrying metallic part
Remarks
UL 508, CSA-C22.2 No. 14, EMC Directive (EN 61000-6-4, EN 61000-6-2)
RoHS Directive (EN 50581), FCC Part 15 Subpart B Class AConformity Standards
KC (KN 61000-6-4, KN 61000-6-2)
LED Unit：45mA
Operating Ambient Temperature
Operating Ambient Humidity
Storage Ambient Temperature
Storage Ambient Humidity
Mounting Location
Withstand Voltage
-20℃ 〜 +50℃
Less than 90% RH (No Condensation)
-30℃ 〜 +60℃
Less than 90% RH (No Condensation)
Indoor Only
Model
LR6-□02WCNW
500VAC applied for 1min between live part and non-current carrying metallic part without breaking insulation
UL Recognized Component (File No.E215660)
Protection Rating
● This product is designed for use on a flat surface for a Type 1 Enclosure.
(Conformity requirements for UL Standard)
● Use a "class 2" power supply specified in the guidelines under UL1310. (Conformity requirements for UL Standard)
● This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These restrictions are limited to cases where this equipment is operated in a business district, and it is designed to take the
relevant protective measures against electromagnetic noise hindrance.
● This product must not be used in residential areas. (Conformity requirements for the CE Marking)
Due to the characteristics of the LED elements, a variation in difference of the color tone and brightness
of every product may occur.
