54
Buzzer sound No.4 was measured from the total circumference of the Buzzer Unit at 1m
Buzzer Unit ：40mA (※1)
LED Unit ：40mA
100-240V AC (50/60Hz)
90-250V AC (50/60Hz)
Buzzer Unit ： 1.5W (※1)
LED Unit ： 1.5W
LED Unit ： 1.8W
Buzzer Unit ： 1.8W (※1)
at 25℃：25A/ Less than 2ms (Cold-start)
at 50℃：50A/ Less than 2ms (Cold-start)
0.44kg+(0.035kg)×Tiers+[0.035kg]
0.50kg+(0.06kg)×Tiers+[0.060kg]
0.32kg+(0.06kg)×Tiers+[0.060kg]
0.25kg+(0.035kg)×Tiers+[0.035kg]
(LED Unit) + [Buzzer Unit]
Typ.88dB
Typ.85dB
Buzzer Unit ：250mA (※1)
LED Unit ：45mA
LR□-□M2□□□W
none
LED Unit ： none
Buzzer Unit ： 0.2W
Body Unit ： 0.2W
1500VAC applied for 1min Between live part and non-current carrying metallic part without breaking insulation
LR4
PJ
WJ
PJ
WJ
0.60kg+(0.06kg)×Tiers+[0.060kg]
0.54kg+(0.035kg)×Tiers+[0.035kg]
LJ
LJ
LR6
LR4
LR6
General Specifications（ M2 ）
Max.
Operating Voltage Range
Typ.
Signal Wire Current
Rated Voltage
（Per Unit）
Rated Power
Consumption
（Per Unit）
Inrush Current
Model
Power Supply Wire
Signal Wire
Max.
Typ.
Standby Power Consumption
Mounting Direction
Environmental Condition
Setting
Insulation Resistance
Outer Dimensions
Buzzer Sound/
Typical Frequency
Operating Ambient Temperature
Operating Ambient Humidity
Storage Ambient Temperature
Storage Ambient Humidity
Mounting Location
Protection Rating
Withstand Voltage
Flashing Rate
Mass
(Tolerance ±10%)
Environmental Condition
Sound Pressure Level
No.1
No.2
No.3
No.4
Rapid Intermittent Beep / 3378Hz
Continuous Beep Sound / 3378Hz
Rapid Hi-Lo / 2016Hz&3012Hz
Sweep Sound / 1000Hz-4032Hz
Refer to Section 3 “
Part Names and Outer Appearance”
Depending on DIP Switch Settings.Refer to Section 6 “Buzzer Pattern Set-up”.
60±2 Flashes Per Minute
Upright
Upright
IP65(IEC 60529) / NEMA TYPE 4X,13
IP54(IEC 60529) / NEMA TYPE 4X,13
More than 1MΩ at 500VDC between live part and non-current carrying metallic part
-20℃ 〜 +50℃
Less than 90% RH (No Condensation)
-30℃ 〜 +60℃
Less than 90% RH (No Condensation)
Indoor Only
UL 508, CSA-C22.2 No. 14, EMC Directive (EN 61000-6-4, EN 61000-6-2)
RoHS Directive (EN 50581), FCC Part 15 Subpart B Class A
KC (KN 61000-6-4, KN 61000-6-2) (※2), Low Voltage Directive(IEC/EN60947-5-1,EN62471)(※2)
(※1) Environmental Condition: Buzzer sound No.2 (Continuous Beep Sound)
(※2) Except LJ Type
UL Recognized Component (File No.E215660)
Conformity Standards
Remarks
● When a regulated power supply is not being used, select a fuse that meets class CC or more.
● Use a fuse holder with UL standard certification. (Conformity requirements for UL Standard)
● This product is designed for use on a flat surface for a Type 1 Enclosure.
(Conformity requirements for UL Standard)
● This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These restrictions are limited to cases where this equipment is operated in a business district, and it is designed to take the
relevant protective measures against electromagnetic noise hindrance.
● This product must not be used in residential areas. (Conformity requirements for the CE Marking)
Sound Reduction approximately -10dB,
depending on DIP Switch settings.
Refer to Section 6 “Buzzer Pattern Set-up”
Due to the characteristics of the LED elements, a variation in difference of the color tone and brightness
of every product may occur.
LJ
