Patlite LR4 - Page 76

φ54
■
SZK-003 [W/U/K]
(Unit: mm)
1.4 N m
Recommended Torque
M5
Screw/Nut
Mounting Dimensional Drawing
Mounting Hole
(φ6×4places)
Wire Distribution
Hole (φ15)
Pr
oduct Mounting
Hole (3 pl
aces)
(2)
70
72
90
55
(54.5)
8
76
Wallmount Bracket
SZK-003 [W/U/K]
Compatible Models
Specifications
Material
Mounting Location
Model
SZK-003 [W/U/K]
Remarks
Mass (Tolerance ±10%)
Indoor Only
PC
0.07kg
Protection Rating
IP65 (with product attached)
Outer Dimensions
Mounting Dimensional Drawing
There are no contents of controlled
substances exceeding the threshold
for the RoHS Directive.
（Unit
:
mm
）
003
Wallmount Bracket
SZK -
Model
Body Color
Model Number Configuration
↓
W
Off-white
U
Silver
K
Black
-
WJ LR7
,
-
WJ
LR6 WT KT
※
1
(※1)Direct Mount
KT
