Insert the 4 supplied AA batteries
and close the lid to the battery
compartment.
Feed the rear chassis over the spin-
dle and screw in the supplied m4 x
26mm machine screws.
Using the Allen key provided tighten
up the grub screw on each handle.
Feed the rear fascia over the handle
and x to the chassis, inserting it at
the top rst and then pushing down
on the bottom, until you hear a click.
