17
1
/ 4 " THREADED ROD
4 REQ.
SECURE ANGLE
IRON TO BOTTOM
OF FURNACE WITH
3 #8 x
3
/ 4 " SCREWS
TYPICAL FOR 2 SUPPORTS
1" SQUARE, 1
1
/ 4 " x 1
1
/ 4 " x
1
/ 8 " ANGLE IRON
OR UNI-STRUT MAY BE USED
(2) HEX NUTS, (2) WASHERS & (2) LOCK WASHERS
REQ. PER ROD
8" MIN FOR DOOR
REMOVAL
OUTER DOOR
ASSEMBLY
A05027
Fig. 15 --- Horizontal Unit Suspension
A02014
Fig. 16 --- Horizontal Suspension with Straps
PG8J/M
