Specifications
 Power Supply Voltage: …… 85-240 VAC, 12-30 VDC (factory set)
 Power Supply Current: …… 150 mA max
 Sensor Type: …… Piezoelectric Sensing Element
 Standard Vibration Ranges: …… 0-5g pk, 0-1.5 ips pk, 0-3 ips pk, 0-50 mils pk-pk, 0-15 mils pk-pk
(factory set)
 Frequency Response +/-3dB: …… 2Hz to 1Khz (120 – 60,000cpm)
 Turn on Time Delay: …… 20 seconds
 Alert/Alarm Time Delay: …… 0-45 seconds
 Alert/Alarm Function Select: …… Latch or Continuous
 Alert/Alarm Switches: …… 5A/245Vac Triac (SPST) or 10A/245Vac – 5A/30Vdc Form C Relay (SPDT)
 Operating Temperature Range: …… -22 to 158°F (-30 to 70°C)
 Storage Temperature Range: …… -40 to 257°F (-40 to 125°C)
 Relative Humidity:.….. NEMA 4X Rating
 Case Dimension W x H x D: …… 3.5 x 2.8 x 3.5in. (90 x 70 x 90mm)
 Weight: …… 1.85 lbs. (839 grams)
 Case Material: …… Aluminum Alloy
 Input/Output Electrical Connectors: …… Screw Terminals
 Screw Terminal Wire Size: …… 24-14 AWG (0.2-2.5 mm
2
)
 Wiring Interface: …… Cord Grips (wire comp. dia. 0.2”- 0.35”) or ½” NPT Conduit Hubs
 Mounting Hole Size: …… 0.21 inches
 Mounting Screw Torque: …… 2- 5 ft. lbs. (3-7Nm)
 LED Indicators:
Power: - Green
Alarm: - Red
Alert: - Yellow
 Alert/ Alarm Setpoint: …… Single Turn Potentiometer (10-100% Full Scale Range)
 Reset Function: …… Momentary Pushbutton Switch and/or Remote to Common.
