M758LMR Mainboard User’s Manual
Key Features
The key features of this mainboard include:
Socket-370 Processor Support
Supports PPGA Celerons and FCPGA Pentium III CPUs
Supports 66MHz, 100MHz or 133MHz FSB
All processors are automatically configured using firmware and a
synchronous/asynchronous Host/DRAM Clock Scheme.
Memory Support
Two DIMM slots for 168-pin SDRAM memory modules
Support for 66MHz, 100MHz, & 133MHz memory bus
Maximum installed memory is 2 x 512MB = 1 GB
Expansion Slots
Two 32-bit PCI slots
Onboard IDE channels
Primary and Secondary PCI IDE channels
Support for PIO (programmable input/output) modes
Support for Multiword DMA modes
Support for Bus Mastering and Ultra DMA 33/66 modes
Power Supply and Power Management
ATX power supply connector
ACPI and previous PMU support, suspend switch,
keyboard power on/off
Supports Wake on Modem, Wake on LAN and Wake on
Alarm
