CPU Type/Core
Voltage/Ratio/
Frequency
These items show the type, core voltage,
ratio and frequency of CPU installed in your
system.
CPU/DRAM
Speed/Frequency
These items decide CPU/DRAM
speed/frequency installed in your system.
Hardware Monitor Page
This page sets some of the parameters for the hardware monitoring
function of this mainboard.
AMIBIOS SETUP – HARDWARE MONITOR
(C) 2000 American Megatrends, Inc. All Rights Reserved
*** System Hardware ***
Vcore 1.616V
Vcc 1.8V 1.792V
Vcc 3.3V 3.392V
Vcc 4.945V
+12V 12.032V
Vcc2.5V 2.532V
SB5V 4.962V
VBAT 3.472V
SYSTEM Fan Speed 0 RPM
CPU Fan Speed 1308 RPM
SYSTEM Temperature 33°C/91°F
CPU Temperature 41°C/105°F
ESC : Quit ↑↓←→ : Select Item
F1 : Help PU/PD/+/- : Modify
F5 : Old Values (Shift)F2 : Color
F6 : Load BIOS Defaults
F7 : Load Setup Defaults
System/ CPU
Temperature
These items display Power, CPU and System
temperature measurement.
FANs & Voltage
Measurements
These items indicate cooling fan speeds in
RPM and the various system voltage
measurements.
29
