lmportant safety instructions
Contents
1. To avoid personal injury, users should not disassemble it by themselves,
since the energy storage LiFePO
4 battery has unsafe voltage inside. If need
repairs, please contact our company’s professional maintenance personnel.
2. Do not install the energy storage LiFePO
4 battery in a place where children
can touch.
3. Do not install the energy storage LiFePO
4 battery in harsh environments
such as damp greasy, flammable, explosive, or dust accumulation.
4. When the energy storage LiFePO
4 battery is working, please do not open the
box.
5. lt is recommended to install a suitable fuse or circuit breaker externally.
6. After installation, check whether all line connections are tight to avoid the
risk of heat accumulation due to virtual connection.
7. Wall mounted energy storage battery shall be charged with 51.2V DC power
supply, parallel connection with other AC power supply or different voltage
and brand batteries is prohibited.
1. Basic information
2. lnstallation process
3. Installation instructions
4. Schematic diagram of connecting
6. BMS communication settings
7. LCD screen description
8. Technical parameter list
9. Maintenance and conservation
10. Warranty record card
3~4
5
5~8
9~10
13~14
15~16
16
17
18
lmportant safety instructions
Please keep this manual for future reference.
This manual contains all the safety. installation and operation instructions of
the 16S series energy storage LiFePO
4 battery.
Please read all instructions and precautions in the manual carefully
before installation and use.
1 2
3.1 Installation notes
5~6
3.2 Installation and wiring
6
3.4 Schematic diagram of the installation
7~8
3.3 Recommended external wiring diameter and switch selection
6
5. LED instructions
11~12
