ENGINE SPECIFICATIONS - 12
ALL ALL ALL
MODEL HO303 EX343 ZR409/ZR450
Fuel Pressure 57-62 psi @ WOT 57-62 psi @ WOT
STD. FCC
Fuel Pressure - FCC 57-62 psi
Returnless to Rail (WOT)
Fuel Pressure - LPFP 7 - 9 psi 7 - 9 psi 7 - 9 psi
ALL ENGINES (WOT) (WOT) (WOT)
PCM MASTER FUEL PRESSURE SPECIFICATIONS - 2011
IMPORTANT: FUEL PRESSURE MEASUREMENT MUST BE MADE WITH THE
ENGINE UNDER LOAD.
MODEL HO303 EX343 ZR409/ZR450 HO303 CES EX343 CES ZR409/ZR450 CES
Coolant
200°F 200°F 200°F 200°F 200°F 200°F
Over-Temperature DTC 116/217 DTC 116/217 DTC 116/217 DTC 116/217 DTC 116/217 DTC 116/217
Sensor MIL MIL MIL Check Gauges Lamp Check Gauges Lamp Check Gauges Lamp
and Buzzer and Buzzer and Buzzer and Buzzer and Buzzer and Buzzer
Engine Derates Engine Derates Engine Derates Engine Derates Engine Derates Engine Derates
Exhaust Manifold
240°F 240°F 240°F
Water Temperature Not Not Not DTC 1415/1416/ DTC 1415/1416/ DTC 1415/1416/
Sensors Applicable Applicable Applicable 1417/1418 1417/1418 1417/1418
Check Gauges Lamp Check Gauges Lamp
and Buzzer and Buzzer
Engine Derates Engine Derates
Low Oil < 5 psi @ idle / < 5 psi @ idle / < 5 psi @ idle / < 5 psi @ idle / < 5 psi @ idle / < 5 psi @ idle /
Pressure Sensor < 24 psi @ 4000 < 24 psi @ 4000 < 24 psi @ 4000 < 24 psi @ 4000 < 24 psi @ 4000 < 24 psi @ 4000
DTC 524 DTC 524 DTC 524 DTC 524 DTC 524 DTC 524
MIL MIL MIL Check Gauges Lamp Check Gauges Lamp Check Gauges Lamp
and Buzzer and Buzzer and Buzzer and Buzzer and Buzzer and Buzzer
PCM MASTER WARNING/ALARM SPECIFICATIONS - 2011
NOTE: FOR NEW BOAT PROPPING, IT IS RECOMMENDED THAT OEMS PROP TO THE MAXIMUM RPM LISTED.
