Control and Settings (continued)
Main Parameters
Parameter
Function
Component Heating by Topheat (T/H)
T/H Power% (max)
Topheat intensity - max limit within that zone
T/H Power% (min)
Topheat intensity - min power for that zone (Manual Mode
Only)
Limit (temp)
Max component temperature for zone
PCB Heating by Backheat (PCB Preheater)
B/H Power% (max)
Backheat intensity - max limit within that zone
Limit (temp)
Max PCB temperature for zone
Other Parameters
Time (sec)
Duration for zone
Wait for PCB Temp
A tick in the zone 2 checkbox will make the software wait for
the previous zone’s B/H (PCB Temp) limit to be met before
continuing with zone 2
Ramp rate (°C/Sec) (Component Temperature)
 If a +ve value is set time for zone, T/H power will be
adjusted to always maintain this ramp rate
 If value=0, the software will maintain temps for the
time duration set (Soak)
 a -ve value, cool down, the software will control the
rate of cooling if a T/H power is set.
Align (Time and Power)
Controls topheat for alignment of component within IR spot
Standby Power
Allows PCB Preheaters to stay warm during standby. Normally
set to 5 – 10% Power
Preferences
Go here to change software skin to different colours
Backheater Zone Control
Switches PCB Preheater Zone 2 (outer) on or off.
Selected/checked = on
