10. Feed the Rope through the metal loop and cam of the Rope Cleat. Repeat for the other side.
NOTE: Make sure that both Ropes are adjusted to equal lengths before use.
11. To attach the Foot Strap, assemble one Safety Link to each of the Eye Bolts located under
the Foot End Cross Member.
12. Tighten the Safety Link locking nuts.
Operating the MVe
®
Fitness Reformer
Attaching the Reformer Springs
The MVe Reformer comes with 5 Reformer Springs as described below:
• Heavy – One heavy spring marked with a red tab.
• Medium – Two medium springs marked with yellow tabs.
• Light – Two light springs marked with blue tabs.
WARNING: At least one spring must be attached to the Gear Bar at all times.
To attach a Spring to an eye bolt on the Gear Change Bar:
1. Pull and lift the end of the Spring.
2. Insert the Spring hook through the respective eye bolt.
Adjusting the Gear Change Bar
The Gear Change Bar has 4 positions: -1, 1, 2, and 3. To adjust the Gear Change Bar:
1. Remove all but the center Spring.
2. Pivot the Spring end of Gear Change Bar up.
3. Move the Carriage either toward the head or foot end of the unit until the Bar drops
into the desired locating slot.
NOTE: Once the Spring end is lifted, move the Carriage to relocate the Gear Change Bar.
WARNING: Make sure that the Gear Change Bar is fully engaged in one of the 4 positions
before beginning to exercise. Failure to do so could result in damage to the unit
or injury to the user.
7
