Adjusting the footbar continued:
WARNING: Verify that both Foot Bar Support Bar slotted ends are fully engaged
before beginning any exercise. Failure to do so could result in serious injury.
NOTE: The Foot Bar can be stored as shown in the accompanying figure.
Stacking the MVe Reformer:
The MVe Reformer is unique in its design and can be easily stacked while configured at
the preferred working height for Pilates reformers and without removal of any parts.
1. Place the Gear Bar in position #3 (see Gear Bar instructions on page 7).
2. Fold the Foot Bar down so it rests against the cushion of the Reformer Carriage.
3. Fold the Foot Bar Support Bar in the opposite direction from the Foot Bar so it
rests on the Gear Bar.
4. Retract the respective Pull Pins and allow each Riser to drop into the Head End
Cross Member.
5. Hook each Double Loop strap onto its Storage Post located behind the Shoulder Pad.
6. Disengage each Rope from its Cleat by pulling the Rope up from between the
spring loaded cam locks.
7. Pull the Shoulder Pad Release Levers toward the outsides of the unit and fold the
Shoulder Pads down to the wood of the Carriage.
8. With one person at each end, grab the retractable Lift Handles and lift the unit.
9. Nest the units by lining up the Head End and Foot End Legs respectively and
lowering the top unit into the wells of the lower machine.
CAUTION: Verify that the all 4 Stacking Bumpers of the upper unit contact the tops of
the Rails of the lower unit before attempting to stack additional machines.
