6 Technical Data
USB
USB mode USB 2.0 Full-speed
USB port Plug type A
LIN
LIN standard 2.2, downward-compatible
LIN connection D-Sub, 9-pin, LIN signal on pin 4
Time stamp resolution 1 µs
Mastertask resoloution
1 ms
Transceiver
NXP LIN transceiver TJA1028T/3V3/20 or
TI LIN transceiver TLIN10283DDRQ
Bit rates
1 to 20 kbit/s
Scheduler
Initialized by software, processed by hardware,
8 schedule tables with 256 slots in all configurable
Galvanic isolation up to 500 V
Power supply
PLIN-USB (without Transceiver) 5 V DC via USB port
Transceiver
6 to 28 V DC via D-Sub, Pin 9
Current consumption
USB 30 mA
Transceiver max. 20 mA at 12 V
Measures
Size without cablel (W x L x H) 43 x 86 x 21 mm
Length USB connection cable 60 cm
Weight including cable 80 g
Environment
Operating temperature -40 to +85 °C (-40 to +185 °F)
Temperature for storage and
transport
-40 to +100 °C (-40 to +212 °F)
Relative humidity 15 to 90 %, not condensing
Ingress protection (IEC 60529) IP20
