6.4 Preset Mode
1. In this mode, the Rear Control Light is on to indicate panel V & I controls are de-activated.
2. There are 3 preset output P1/ P2/ P3 at the Recall Selection Switch (9)
P 1565/1575/1585 or (10) P 1570/1580.
3. The preset values are factory set as following table.
4. End user can set his own output rating, please refer to paragraph 6.5.
6.5 Set Mode
First enter into the Set Mode by pushing Switch (8) to Set Mode slot.
The power supply is then ready to be preset.
6.5.1 To define the preset output P1/ P2/ P3
1. Select the Recall Switch to the position P1, P2 or P3 which you want to set
2. Adjust the front panel voltage control knob to set your desired voltage value
3. Adjust the front panel current control knob to set your desired current limit value
4. Repeat the procedure for remaining recalls P1, P2, P3 if desired.
5. Move Mode Switch from Set to Preset position to confirm your settings.
Remarks:
All the set values in the presets will be kept even after the power supply has been turned off.
Always check output voltage of Presets before connect to Load. To check the preset values,
move Mode Switch to Preset position. Move the Recall Switch to P1, P2 or P3. The V and I
settings of corresponding RECALL P1, P2, P3 will be show on the panel meters.
-40-
