PeakTech 1565 User Manual

10 Specifications
Model
P 1565
P 1570
P 1575
P 1580
P 1585
Output
Variable Output Voltage
1 – 16V DC
1 – 16V DC
1 – 32V DC
1 – 32V DC
1 – 60V DC
Variable Output Current
0 - 40A
0 – 60 A
0 - 20A
0 – 30A
0 – 15A
Voltage Regulation
Load (0-100%)
50mV
Line (170 – 264V AC Variation)
20mV
Current Regulation
Load (10-90% Rated Voltage)
150mA
200mA
100mA
150mA
100mA
Line (170 – 264V AC Variation)
50mA
Ripple & Noise
Ripple & Noise (rms)
5mV
Ripple & Noise (Spitze-Spitze)
Voltage
50mV
100mV
Current Ripple & Noise (rms)
70mA
100mA
30mA
40mA
15mA
Meter Type & Accuracy
Voltage Meter
3-stellige LED-Anzeige (+/-0,2% + 3 dgt.)
Current Meter
3-stellige LED-Anzeige (+/-0,2% + 3 dgt.)
General
Input Voltage
220 – 240V AC 50/60Hz
Full Load Input current
3,15A
4,7A
3,1A
4,5A
4,5A
Efficiency
85,50%
85,00%
87,00%
86,00%
88%
Switching Frequency
65 - 85kHz
65 - 85kHz
75 - 85kHz
75 - 95kHz
65 – 85kHz
Transient Response Time
(50-100% Load)
1,5ms
Power Factor Control (PFC)
Power Factor Correctionr >0,95 at optimal Load
Cooling Method
Thermostatic Control Fan from Zero to full speed
Protections
Überlast, Kurzschlussschutz im CC-Modus, Überspannungsschutz,
Übertemperaturschutz
Special Functions
3 User defined VI preset, Remote control V, I and output on-off
Operation Temperature
0 ... +50°C; RH < 70 %
Storage Temperature
-10 ... +60°C; RH < 80 %
Dimensions (BxHxT) in mm
200x90x255
200x90x325
200x90x255
200x90x315
200x90x275
Weight
2,6kg
3,2kg
2,6kg
3,2kg
3,2kg
-51-
