When “Internal Preset Memory” tab is being selected, the buttons are used to save and load
the setting of Internal Preset Memory.
Click to save Internal Preset Memory setting to CSV file.
Click to open and load setting from CSV file to program.
Click to print the setting to print
12.8. Setting
In the setting page, you can do general setting for the program.
You can select language for the program
You can select the COM Port for power supply connected
You can set sampling time for data log by adjust slide bar
You can set your output voltage upper limit (UVL) value to further safeguard your low voltage
applications.
You can set your output current upper limit (UCL) value to further safeguard your low current
applications.
-60-
