PeakTech 1650 User Manual

4.4. AC Current
Range
Resolution
Accuracy
40 A 10 mA
±
2,5% rdg. + 8 dgt.
400 A 100 mA
±
2,8% rdg. + 5 dgt.
Overload protection: 400 A
Frequency range: 50/60 Hz
4.5. Resistance
Range
Resolution
Accu
racy
400
Ω
100 m
Ω
±
1,0% rdg. + 4 dgt.
4 k
Ω
1
Ω
± 1,5% rdg. + 2 dgt. 40 k
Ω
10
Ω
400 k
Ω
100
Ω
4 M
Ω
1 k
Ω
±
2,5% rdg. + 3 dgt.
40 M
Ω
10 k
Ω
±
3,5% rdg. + 5 dgt.
Overload protection: 250 V AC/DC
4.6. Capacitance
Range
Resolution
Accuracy
40 nF 10 pF
±
5,0% rdg. + 20 dgt
400 nF 100 pF
± 3,0% rdg. + 5 dgt
4 µF 1 nF
40 µF 10 nF
400 µF 100 nF
±
4,0% rdg. + 10 dgt
4 mF 1 µF
±
5,0% rdg. + 10 dgt
Overload protection: 250 V AC/DC
4.7. Frequency
Range
Resolution
Accuracy
Sensitivity
4 kHz 1 Hz
±1,2% rdg.+2 dgt.
<0,3 V
pp
40 kHz 10 Hz
400 kHz 100 Hz
4 MHz 1 kHz <1 V
pp
40 MHz 10 kHz
<3 V
pp
Overload protection: 250 V AC/DC
-25-
