Page #32 background imageLoading...
Page #32 background image
3. Technical Data
3.1. Low resistance
Range
Resolution
Accuracy
Current
400 mΩ
0.1 mΩ
± (1%+10dgt.)
200 mA
4 Ω
1 mΩ
20 mA
40 Ω
0.01 Ω
2 mA
Overload protection: 500 mA / 230 V
Max. input Voltage: 30 V DC / 25 V
pp
AC
3.2. Ohms
Range
Resolution
Accuracy
400 Ω
0.1 Ω
± (1.0% + 4 dgt.)
4 kΩ
1 Ω
± (1.5% + 2 dgt.)
40 kΩ
10 Ω
400 kΩ
100 Ω
4 MΩ
1 kΩ
± (2.5% + 3 dgt.)
40 MΩ
10 kΩ
± (3.5% + 5 dgt.)
Overload Protection: 30 V DC / 25 V
pp
AC
3.3. DC Current
Range
Resolution
Accuracy
400 µA
0.1 µA
± (1.5%+5 dgt.)
4000 µA
1 µA
40 mA
0.01 mA
400 mA
0.1 mA
Overload protection: 500 mA / 250 V
-31-
