PeakTech 3430 - Familiarization; Test Lead Connection

40
Capacitance
Range
Resolution
Accuracy
22 nF
10 pF
± 2,5% of rdg. + 3 dgt.
220 nF
100 pF
2,2 µF
1 nF
22 µF
10 nF
220 µF
100 nF
2,2 mF
1 µF
22 mF
10 µF
220 mF
100 µF
Frequency range
Range
Resolution
Accuracy
10 Hz … 220 MHz
0,01 Hz
± 0,2% of rdg. + 3 dgt.
3. Familiarization
3.1 Connection of test leads
The supplied test leads can be used for measurements up to 1000
V. High-voltage measurements should be done with care and in
presence of a person, who is educated in first-aid.
Caution!
The max. input voltage for this instrument is 1000 V DC or 750 V
AC and to be on the safe side, these values mustn´t be passed.
The max. voltage-difference between COM-input and earth is 500
V DC/AC
eff
. Higher voltage-differences may cause personal injury
or damage of the unit.
