Page #40 background imageLoading...
Page #40 background image
39
AC Current
Range
Resolution
Accuracy
220 μA
10 nA
± 1,0% of rdg. + 3 dgt.
2200 μA
0,1 μA
22 mA
1 μA
220 mA
10 μA
10 A
1 mA
± 1,5% of rdg. + 3 dgt.
Overload protection: 250 mA/1000 V
10 A/1000 V
Max input current: mA-range: 250 mA
10- A-range: 10 A
Frequency range: 40 … 400 Hz
Resistance Range
Range
Resolution
Accuracy
220 Ω
0,01 Ω
± 0,8% of rdg. + 2 dgt.
2,2
0,1 Ω
22
1 Ω
220
10 Ω
2,2 MΩ
100 Ω
22
1
220
10
Dioden/Continuity test
Diode: Measures forward resistance of semiconductor
junction in kΩ a test current of approx. 1,5 mA;
forward voltage max. 2,7 V
Continuity: The buzzer sounds if the measured resistance is
less than approx. 30 Ω
