Low Battery Indication “ ” is displayed if battery voltage
drops below operating voltage
Battery 7.2 V; 1300mAh rechargeable battery
Fuse mA, μA ranges:
0.8A/1000V (6,3x32mm)
ceramic fast blow
A-range:
10A/1000V (10x32mm)
ceramic fast blow
Safety This meter is intended for origin of
installation use and protected, against
the users, by double insulation per
EN61010-1 and IEC61010-1 2nd
Edition (2001) to Category IV 600V
and Category III 1000V; Pollution
Degree 2. The meter also meets UL
61010-1, 2
nd
Edition (2004), CAN/CSA
C22.2 No. 61010-1 2
nd
Edition
(2004), and UL 61010B-2-031, 1st
Edition (2003)
Dimensions (W x H x D) 81 x 175 x 53 mm
Weight 390 g
-115-
