MAN 06 033774 – technical_guide_ DIRIS_A40_A41_C.doc40/Z41 - B 21/27
4.3 - Modification of DIRIS configuration with “writing” function.
Configuration of CT primary (address Hex. 202) : TC = 1500 = 05DC en hexadecimal
Master request:
Slave
Function
Address
Address
Value
Value
CRC16
High-order
Low-order
High-order
Low-order
07
06
02
02
05
DC
2B1D
1500 in decimal
DIRIS reply:
Identical to master request
After having modified the parameters of the DIRIS, and to record them, it is necessary to send
the backup order:
Slave
Function
Address
Address
Value
Value
CRC16
High-order
Low-order
High-order
Low-order
07
06
06
00
00
00
8924
DIRIS reply:
The DIRIS does not answer this order.
Configuration of network type (address Hex. 200) , Type = 3 NBL = 3 in hexadecimal
Master request :
Slave
Function
Address
Address
Value
Value
CRC16
High-order
Low-order
High-order
Low-order
07
06
02
00
00
03
C815
3 NBL
DIRIS reply:
The DIRIS does not answer this order.
After having modified the parameters of the DIRIS, and to record them, it is necessary to send
the saving order:
Slave
Function
Address
Address
Value
Value
CRC16
High-order
Low-order
High-order
Low-order
07
06
06
00
00
00
8924
DIRIS response:
The DIRIS does not answer this order.
