MAN 06 033774 – technical_guide_ DIRIS_A40_A41_C.doc40/Z41 - B 25/27
5.2. Configuration of voltage dips function (SAG)
This function is used to detect voltage dips according to EN 50160 standard (Voltage characteristics of electricity
supplied by public distribution systems)
Example : Discover voltage dips ( SAG) with a threshold in 10 % and a hysteresis of 2
%. Reading information with communication
DIRIS configuration (see instruction manual : 876 588) :
 Voltage dips threshold (SAG) = dAtA SAG 10 % )
 Voltage dips hysteresis = dAta HySt SAG 2 %
Reading of fault parameter:
Master request :
Slave
Function
Address
Address
Value
Value
CRC16
High-order
Low-order
High-order
Low-order
01
03
0D
00
00
01
86A6
DIRIS response:
Salve
Function
Number of
Word 1
CRC16
bytes
01
03
02
0005
7847
5 = U12
Reading of fault value:
Master request :
Slave
Function
Address
Address
Value
Value
CRC16
High-order
Low-order
High-order
Low-order
01
03
0D
01
00
02
86A6
 = 10 %
Un
Threshold (Un – 10 % de Un)
Hysteresis (Un – 2% de Un)
