Scanner Installation
Installing the Scanner
2-10 Installation Guide for the OpScan iNSIGHT 70 Scanner
Figure 2-1 Location of the Power Supplies
Figure 2-2 Adjustment Locations
Solenoid
and DC
Motors
Supply
+5, +/-15V Logic Supply
Printer
Transformer
PWRC Board
Solenoid Boost Voltage
+5V LED
Supply
+5V Adjustment
+15V Adjustment
-15V Adjustment
Logic Power Supply
+5V Adjustment
LED Power Supply
+12.5V
Adjustment
DC Output
Solenoid and DC
Motor Power Supply
