3-10 Installation Guide for the OpScan iNSIGHT 70 Scanner
Board/Connector Relationship
Figure 3-4 illustrates the relationship between PC boards attached to the bulkhead
inside the cabinet and the connectors on the exterior surface of the cabinet in a
network configuration.
Figure 3-4 Network, Board/Connector Locations
MONITOR
KEMCON
KEYBOARD MOUSE
CAMERA
CONTROLLER
BOARD
SCANNER
CONTROLLER
MAIN BOARD
PRTCON
NETCOM
INPUT POWER
No Board Required for
Monitor (Pass Through)
LINE PRINTER
NETWORK
To Next Page
