Peavey AAM 802

12
Output Specifications:
Function Minimum Output Level Bal/ Connector
Load UnBal.
Ohms Min** Max
Main L/R 600 +4 dBu +22 dBu Bal. 1/4" TRS: Tip (+),
Ring (-)
Sleeve Ground
+4 dBu +22 dBu Bal. XLR: Pin 1 Ground
Pin 2 (+),
Pin 3 (-), (Bal.)
Monitors 600 +4 dBu +22 dBu Bal. 1/4" TRS: Tip (+)
Ring (-),
Sleeve Ground
+4 dBu +22 dBu Bal. XLR: Pin 1 Ground,
Pin 2 (+),
Pin 3 (-), (Bal.)
Mono 600 +4 dBu +22 dBu Bal. 1/4" TRS: Tip (+),
Ring (-),
Sleeve Ground
+4 dBu +22 dBu Bal. XLR: Pin 1 Ground
Pin 2 (+),
Pin 3 (-), (Bal.)
Effects 600 +4 dBu +22 dBu Unbal. 1/4" Phone: Tip (+),
Sends Sleeve Ground
Channel 600 +4 dBu +22 dBu Unbal. 1/4" TRS: Tip Send,
Insert Send Ring Return,
Sleeve Ground
Headphone 8 +4 dBu +22 dBu Unbal. 1/4: TRS: Tip Left,
(No load) Ring Right,
Sleeve Ground
Tape 2.2 k +4 dBu +22 dBu Unbal. RCA Phono
0 dBu=0.775 V (RMS)
