13
Gain:
Mic Input Gain Adjustment Range: 10 dB to 58 dB
Mic Input to L/R Balance Output 78 dB (Max. Gain)
Mic Input Longest Path 93 dB (Max. Gain)
Line Input Gain Adjustment Range: -10 dB to 38 dB
Line Input to L/R Bal. Output 60 dB (Max. Gain)
Line Input to longest Path 73 dB (Max. Gain)
Stereo Line Input Gain Adjustment Range 10 dB
Stereo Line Input to L/R Balance Output 36 dB (Max. Gain)
Stereo Line Input Longest Path 46 dB (Max. Gain)
Aux Return to L/R Balance Output 34 dB (Max. Gain)
Frequency Response:
Mic Input to L-R Output 11 Hz to 42 kHz +0 dB/-1 dB
Total Harmonic Distortion (THD):
<0.008% 20 Hz to 20 kHz Mic to L-R Output (10 Hz to 80 kHz BW)
Hum and Noise:
Output Residual Noise S/N Ratio Test Conditions
Ref. 0 dBu
Master L/R -100 dBu 104 dB All faders down
-88 dBu 92 dB Master fader nominal,
Channel faders down,
All channels muted
-84 dBu 88 dB All controls nominal,
mic gain min.
Mono -90 dBu 94 dB All faders down
-88 dBu 92 dB Master fader nominal,
Channel faders down,
All channels muted
Monitors -102 dBu 106 dB All faders down
-90 dBu 94 dB Master fader nominal,
All channels muted
Effects -95 dBu 99 dB All controls off
Sends
-82 dBu 86 dB All channel sends nominal
(Hum and Noise Measurements: 22 Hz to 22 kHz BW)
