Peavey Bandit 112 Service Manual

PARTS LIST
- 18 -
P6 8 PIN CONNECTOR 7010-9850-0
ICs
CR5 IC TRIAC MAC97A-6 400V 3131-3430-0
U1 IC DG211CJ ANALOG SWITCH 3131-6770-0
U2, U3 IC UPC4560C-DUAL OP. AMP 3130-2010-0
VOLUMES
VR1 VR XVB12102PHJN15FS-15A 4750-5465-0
VR2 VR XVB12102PHJN15FS-05A1 4750-5415-0
VR3 VR XVB12102PHJN15FS-1B20 4750-5425-0
VR4 VR XVB12102PHJN15FS-25AM 4750-5455-0
VR5 VR XVB12102PHJN15FS-05A 4750-5435-0
VR6 VR XVB12102PHJN15FS-05A1 4750-5415-0
VR7 VR XVB12102PHJN15FS-1B20 4750-5425-0
VR8-VR9 VR XVB12102PHJN15FS-1B 4750-5445-0
VR10 VR XVB12102PHJN15FS-1B10 4750-5475-0
PRIMART ASSEMBLY
CAPACITOR
C1 CM 275V 0.1UF 20% RL 18X 153Z-104M-5-7W
MISCELLANEOUS
CPT1, CPT2 UL1672 #18 RED WIRE 7010-2232-0
FC1, FC2 FUSE CLIP 4134-9141-0
P1 UL1672 #18 RED WIRE 7010-2232-0
P2 UL1672 #18 BLACK WIRE 7010-2233-0
CASING ASSEMBLY
CHASSIS PE017C 1403-6321-0
X'FORMER I/P230V O/P 1806-2509-0
*EU PRODUCT LABEL(EU) PE018C 3000-4821-0
*EU SERIAL LABEL(EU) PE018C 3000-4830-0
*EU PRODUCT LABEL(EU) PE018C 3000-4849-0
*MD PRODUCT LABEL PE01EC 3000-4983-0
*MD PRODUCT LABEL SMALL 3000-4986-0
*MD SERIAL LABEL 3000-4989-0
FUSE F2A 250V 6.4X31.8MM 5120-0204-0
AC CORD SET 3M 3X0.75 7010-9810-0
REVERB SHEET 1450-4830-0
KNOB 1 POWER KNOB 1653-6 1453-1910-0
CR26 OIL SLEEVE ID=1MM 1660-0010-0
SHRINKAGE TUBE ID=5 1660-0620-0
SWITCH SHRINKAGE TUBE ID=25mm 1660-1100-0
AC INLET 2113-1144-0
WASHER METAL ID 3.3 0D8 2600-3005-0640
HS FLAT WASHER M4X0.8X9.7 2600-4008-0973
TRAN FLAT WASHER M4X0.8X9.7 2600-4008-0973
METAL WASHER M5X0.8X10MM 2600-5008-1003
METAL WASHER M6.5X1X17MM 2600-6510-1704
Ref. No. Description Mfr’s Part No.

Peavey Bandit 112 Specifications

General

Power Output	80 Watts RMS
Channels	2 (Clean and Lead)
Effects	Reverb
Effects Loop	Yes
Speaker	12-inch
Outputs	1 x Headphone
Footswitch	Optional (for channel switching)
EQ	3-band EQ per channel
