Peavey Bandit 112 Service Manual

PARTS LIST
- 12 -
DIODES
BR1 DIODE BRIDGE RECT. RS603 4840-0350-0
CR1-CR6 DIODE 1N4148 ATS 4804-1480-C
CR8 DZ 1W 15V AT TEMIC 4838-15V6-2
CR9 DIODE 1-SS-244T-72 AT 4840-7010-1
CR10-CR14, CR16-CR19 DIODE 1N4148 ATS 4804-1480-C
CR20 DIODE 1N5393 200V 1.5A 4805-3930-2
CR21-CR25 DIODE 1N4148 ATS 4804-1480-C
CR26 DIODE DUAL SZ-13886-2 4840-7020-0
CR27 DIODE 1N5393 200V 1.5A 4805-3930-2
CR29-CR33 DIODE 1N4148 ATS 4804-1480-C
CR34 DIODE 1-SS-244T-72 AT 4840-7010-1
CR35 DIODE 1N4148 ATS 4804-1480-C
CR36 DZ 1W 15V AT TEMIC 4838-15V6-2
CR37 DIODE 1N4148 ATS 4804-1480-C
CR39-CR42 DIODE IN4003 AT 4804-0030-2
CR43 DZ 1W 15V AT TEMIC 4838-15V6-2
CR44-CR46 DIODE IN4003 AT 4804-0030-2
CR45,CR47,CR48 DZ 1W 15V AT TEMIC 4838-15V6-2
CR49-CR55 DIODE 1N4148 ATS 4804-1480-C
LED
CR38 LED 3MM RED 3700-2522-R
FUSES
F1-F2 FUSE T1A 250V 6.4X31.8MM 5120-0205-0
JACKS
J1-J4 JACK SOCKET (MONO) 2113-1343-0
J5 8P PIN CONNECTOR P=3.96 2101-1811-0
J6 JM2422-3M WAFER 2101-9400-0
J9, J13 JACK SOCKET (STEREO) 2113-1344-0
J22 JM2422-3M WAFER 2101-9400-0
MISCELLANEOUS
F1-F2 FUSE CLIP 4134-9141-0
J10 SPEAKER WIRE ROR 7010-2213-0
J11-J12 SA083C-WIRE-D 7010-2153-0
J14 SPEAKER WIRE ROR 7010-2213-0
J26-J27 FLAT WIRE 8-PIN 290MM 7408-1290-23
TRANSISTORS
Q2 TR SJE-5331 NPN MOTOROLA 4860-5170-5
Q3 TR SJ-83100 NPN 3A 100V 4860-5130-5
Q4 MPS-6531 4860-5280-5
Q5 MPS-6533/34 4860-5290-5
Q6 TR SJ-73100 PNP 3A 100V 4860-5120-5
Q7 TR SJE-7036/5332 PNP 4860-5180-5
Q9 TR 2N3904 SAMSUNG 4853-9040-5
Q10 FET J-174 P-CHANNEL IDSS 490J-1740-5
Ref. No. Description Mfr’s Part No.

Peavey Bandit 112 Specifications

General

Power Output	80 Watts RMS
Channels	2 (Clean and Lead)
Effects	Reverb
Effects Loop	Yes
Speaker	12-inch
Outputs	1 x Headphone
Footswitch	Optional (for channel switching)
EQ	3-band EQ per channel
