EFFECTS RETURN-INSTRUMENT (27)
Input for returning signals from external low-level effects or signal processing equipment for the Instrument
Channel. (Footswitchable).
REMOTE SWITCH JACK (28)
Provided for the connection of a 2-button, remote footswitch (optional). The footswitch is used to defeat the
effects loop on the Instrument Channel and also allows the user to remotely mute the amplifier.
Note: When the amplifier is muted, the power LED will flash.
IMPORTANT: The mute circuit functions only on the Preamp Out. If the Direct Out is selected to
Instrument (Pre EQ), it will not be muted when the amp is muted.
Note: Effects Loop is footswitchable on the Instrument Channel only.
