Peavey Mini MAX User Manual

Mini MAX
®
AMPLIFIER SPECIFICATIONS
POWER CONSUMPTION:
(1/8 rated power, 1KHz sine wave)
120vac/60Hz, 230vac/50Hz
160 Watts
POWER AMPLIFIER:
(Rated Power < 1% THD, 1KHz sine wave, nominal line)
500 Watts continuous into 4 ohms (minimum load)
300 Watts continuous into 8 ohms
PRE-AMPLIFIER:
Maximum Input Sensitivity:
(PRE GAIN = 10, LOW/MID/HIGH = 5, VOLUME = 10, all voicing switches defeated)
Passive Input 40mV / -25.74dBu
Active Input 110mV / -16.95dBu
Auxiliary Input 1.0V / 2.22dBu
Nominal Input Sensitivity:
(PRE GAIN = 5, LOW/MID/HIGH = 5, VOLUME = 5, all voicing switches defeated)
Passive Input 500mV / -3.80dBu
Active Input 1.40mV / -16.95dBu
Auxiliary Input 1.0V / 2.22dBu
Headphone Output:
(Mono signal split to stereo)
50mW x 2 into 8-ohm minimum load
Noise Floor = -80dB
Features and specifications are subject to change without notice.
Peavey Electronics Corporation • 5022 Hartley Peavey Drive • Meridian • MS • 39305
(601) 483-5365 • FAX (601) 486-1278 • www.peavey.com • ©2015 • 31700105
