18
HHuumm && NNooiissee
OOuuttppuutt RReessiidduuaall NNooiissee SS//NN RRaattiioo ((RReeff.. ++44 ddBBuu)) TTeesstt CCoonnddiittiioonnss
Main -101 dBu 105 dB All level controls down
-88 dBu 92 dB Master level maximum,
Chan Mix levels at minimum,
All Channels Muted
-88 dBu 92 dB All level controls maximum, with input gain at minimum
(Hum & Noise measurements: 22 Hz to 22 kHz BW)
Gain:
Mic input Gain Adj Range: 2 dB to 68 dB
Mic input to Main output 68 dB (Max Gain)
Line input Gain Adj Range -18 dB to 48 dB
Line input to Main output 48 dB (Max Gain)
Frequency Response:
Mic Input to Main Output (with 75 HZ LC filter) 75Hz (-3 dB) to 55KHz (–1 dB)
Total Harmonic Distortion (THD):
0.05% 20Hz to 20KHz Mic to Main output (22 Hz - 22 KHz BW)
Equivalent Input Noise (EIN):
-129.8 dBu (Input terminated with 150 Ohms, maximum gain)
Crosstalk:
80 dB Adjacent Input Channels (20 Hz - 20 KHz)
Common Mode Rejection Ratio (Mic Input):
60dB min (20 Hz - 20 KHz)
70 dB typ @ 1 KHz
Meters: 7 position LED, peak reading.
(0 dB= +4 dBu)
Signal / Overload Indicators: Lights 2 dB below clipping
Dimensions: 19" W x 8.125" D x 1.75" H
Weight: 9 Lbs. 4.1 Kg
Power Requirements: 120VAC 60 Hz, 17 Watts
