The unique die cast frame of the
Scorpion also incorporates a
“square frame” design allowing
these ne transducers to be
utilized in a variety of small,
compact enclosures. Because of
the Scorpion’s “adaptability” to
many enclosure designs (innite
bafe, tuned and ported, etc.),
the modern musician will nd
distinct advantages for utilizing
our Scorpions over competing
transducers. For example, full range
response for guitar amplication
or excellent high end/mid range
response for bi-amped (or tri-
amped) bass and key board rigs.
Our 10” and 12”, 8 ohm
loudspeakers are now available
to discriminating musicians who
require superb sound reproduction,
outstanding durability and high
sound pressure levels.
APPLICATIONS
The S-10825 and S-12825
Scorpion
®
loud speakers are
ideally suited for lead and rhythm
guitar applications. The extended
bandwidth and excellent high
frequency response provide superb
performance for electric bass and
bass bi-amp congurations, and
because of their versatility, the
Scorpion Series also can be used
for many keyboard systems.
SPECIFICATIONS 00013770 00013750
MODEL Scorpion® S - 10825 - 8 Ohm Scorpion S - 12825 - 8 Ohm
DIAMETER 10” 12”
IMPEDANCE 8 Ohms 8 Ohms
POWER CAPACITY 800W peak 800W peak
400W program 400W program
200W continuous 200W continuous
SENSITIVITY 95.1 dB/1W 1m 94.9 dB/1W 1m
USABLE FREQ. RANGE 80 Hz ~ 4 kHz 60 Hz - 4 kHz
VOICE COIL DIAMETER 2.5” / 63.5 mm 2.5” / 63.5 mm
VOICE COIL MATERIAL Kevlar
®
impreganated Kevlar
®
impreganated
cellulose cellulose
NET WEIGHT 7.5 lbs. / 3.4 kg 7.8 lbs. / 3.54 kg
Znom (Ohms) 8 8
Revc (Ohms) 5.58 5.34
Sd (square meters) 0.031 0.050
BL (T/M) 10.60 10.51
Fo (Hz) 102.0 59.4
Vas (liters) 14.6 66.6
Cms (uM/N) 104.3 187.2
Mms (gm) 23.30 38.30
Qms 7.00 5.25
Qes 0.742 0.691
Qts 0.671 0.611
Xmax (mm) 0.06 0.25
Le (mH) 0.40 0.30
SPL (1W 1m) 95.1 94.9
No (%) 2.03 1.96
Vd (cu in/ml) 1.1 / 19 0.76 / 12.5
Pmax (Watts pgm) 400 400
Disp. (cu. in /ml) 91 / 1491 126 / 2064
